Control
35
For the Installer
FIGHTER 1220
Menu 8.3.0 Current limiter
Settings and readings regarding the load monitor are
set on the submenus to this menu.
Current limiter
8.3.0
Menu 8.3.5 Max elec. power
The setting selected on the load monitor card (2) is
shown here knob (101).
Max elec. power
8.3.5
Menu 9.5.17 Return
Pressing the enter button returns you to menu 8.3.0.
Return
8.3.7
Menu 8.4 Return
Pressing the Enter button returns you to menu 8.0.
Return
8.4
Menu 8.3.4 Fuse size
The setting selected on the load monitor card (2) is
shown here knob (100).
16 A
Fuse size
8.3.4
Menu 8.3.1 Current phase 1
Shows the measured current from phase 1
3.5 A
Current phase 1
8.3.1
Menu 8.3.2 Current phase 2
Shows the measured current from phase 2
3.3 A
Current phase 2
8.3.2
Menu 8.3.3 Current phase 3
Shows the measured current from phase 3
3.3 A
Current phase 3
8.3.3
Menu 8.3.6 EBV value
The transfer value must be defined depending on the
current transformers used for the load monitor card.
The value is adjustable between 100 and 900 in incre-
ments of 10. The setting 300 applies for the supplied
current transformers.
300
EBV value
8.3.6
U
U
U
U
U
U
U
Other settings
