The parameters adjustment operation can be carried out by any one of
radio transmitters, as long as it is stored in mode 1 (see paragraph 10.4.1
“Mode 1 memorisation” ).
In the event that no transmitter stored in Mode 1, it is possible to memo-
rise one just for this phase, and delete it straight afterwards (see para-
graph 9.4.4 “Deleting a radio transmitter” ).
CAUTION! – When making adjustments using the transmitter, you must
allow the command unit time to recognise the radio command; in prac-
tice, the keys must be pressed and released slowly, with at least one
second of pressure, one second of release, and so on.
20 – English
English
TABLE 4
Parameters N° Value Action to perform
SbS input configuration on the control unit 1 Open (*) Press T1 once
2 Pedestrian opening Press T1 twice
Flash output configuration on the control unit 1 Flashing light (*) Press T2 once
2 Courtesy light Press T2 twice
3 Gate open indicator Press T2 three times
Motor 1 and motor 2 discharge in closure 1 No discharge (*) Press T3 once
2 0.1s (Minimum) Press T3 twice
3 0.2s Press T3 three times
4 0.3s Press T3 four times
5 0.4s (Medium) Press T3 five times
6 0.5s Press T3 six times
7 0.6s Press T3 seven times
8 0.7s (Maximum) Press T3 eight times
Motor 1 and motor 2 discharge in opening 1 No discharge (*) Press T4 once
2 0.1s (Minimum) Press T4 twice
3 0.2s Press T4 three times
4 0.3s Press T4 four times
5 0.4s (Medium) Press T4 five times
6 0.5s Press T4 six times
7 0.6s Press T4 seven times
8 0.7s (Maximum) Press T4 eight times
(*) Original factory value
TABLE 3
Parameters N° Value Action operation to be carried out at
step 3 in the recognition phase
Pause time 1 10s Press T1 once
2 20s (*) Press T1 twice
3 40s Press T1 three times
4 80s Press T1 four times
Pedestrian opening 1 Open 1 leaf halfway Press T2 once
2 Fully open 1 leaf (*) Press T2 twice
3 2 leaves partially opened to 1/4 of the full
course
Press T2 three times
4 2 leaves partially opened to half of the full
course
Press T2 four times
Motor force 1 Low Press T3 once
2 Medium low (*) Press T3 twice
3 Medium high Press T3 three times
4 High Press T3 four times
Step-by-Step (SbS) function 1 “Open”, “Stop”, “Close”, “Stop” Press T4 once
2 “Open”, “Stop”, “Close”, “Open” (*) Press T4 twice
3 “Open”, “Close”, “Open”, “Close” Press T4 three times
4 Open only Press T4 four times
(*) Original factory value
To program the parameters in Table 3:
01. Press T1 and T2 together (fig. 34) on the radio transmitter for at least
5 s.
02. Release the two keys.
03. Within three seconds, carry out the action set out in Table 4 based on
the parameter to change.
Example: to adjust the pause time to 40 s.
01. Press the T1 and T2 keys and hold them down for at least
5s
