TECHNICAL SPECIFICATIONS OF PRODUCT COMPONENTS
RIVA200 is manufactured by NICE S.p.A. (TV) Italy. Nice S.p.A., in order to improve its products, reserves the right to modify their technical
characteristics at any time without prior notice. In any case, the manufacturer guarantees their functionality and fitness for the intended purposes.
Note: all the technical characteristics refer to a temperature of 20°C.
CL201 command control unit
Type Command control unit for 1 or 2 24 V
motors for automation of automatic gates or
doors, complete with radio receiver for “ECCO5...” transmitters
Technology adopted Electronic board governed by an 8 Bit microcontroller with flash technology
A transformer inside the control unit, but separated from the board, reduces the mains volt-
age to the nominal 24V voltage used in all of the automation system
Maximum cycles frequency 15 cycles/hour at 50°C
Maximum continuous cycle time 5 minutes
Mains power supply 230V
(+10% -10%) 50/60Hz
Nominal absorbed power 170W; at peak the power is 360W for a maximum duration of 2s
Emergency power supply Provision for “PR100” buffer battery connection
Motors output 2, for 24 V
motors with a nominal current of 2A, at peak power the maximum current is
5 A for a maximum duration of 2 s
Flashing light output For ashing lights with 12 V (maximum 21 W) bulb
ECSbus output One output with maximum load of 15 ECSbus units (1 ECSBus corresponds to the con-
sumption of a pair of photocells)
“SbS” input For normally open contacts (the closing of the contact causes the “Step-by-Step or Pedes-
trian Opening” command)
“STOP” inputv For normally closed or normally open contacts and/or for constant resistance of 8.2 KΩ, or
normally closed contacts with self-recognition of the “normal” state (any variation from the
memorised status causes the “STOP” command).
Radio Antenna input 50 Ω for RG58 or similar type of cable
Maximum cable length Mains power supply: 30 m; motors outputs: 10 m; other inputs/outputs: 20 m with antenna
cable preferably shorter than 5 m (observe the warnings regarding minimum gauge and
type of cables)
Ambient operating temperature -20°C ... 50°C
Mounting Vertical, wall-mounted
Protection rating IP44
Dimensions / weight 180 x 240 h 110 mm / 2.8 kg
Remote control compatibility Using “ECCO5...” transmitters, the control unit is able to receive one or more of the follow-
ing commands: “Step-by-Step”, “Partial Open”, “Open Only” and “Close Only”
Memorisable ECCO5... transmitters Up to 150 if memorised in mode 1
Model RIVA200
Type Electromechanical gearmotor for automation of automatic gates and doors
Technology adopted 24 V
motor, reducer with helical gears; mechanical release
Peak torque 250 Nm
Nominal torque 120 Nm
Speed (no load) 1.25 RPM
Nominal torque speed 1 RPM
Maximum cycles frequency 60 cycles/hour
Maximum continuous cycle time 10 minutes
Operating limits The structural features make it suitable for use on gates with a weight of up to 200 kg or a
leaf length of up to 2.3 m and an opening angle of up to 180°
Power input 24 V
Nominal absorbed current 2A, at peak power the maximum current is 5 A for a maximum duration of 2 s
Ambient operating temperature -20°C ... 50°C (at low temperatures the gearmotor efficiency decreases)
Mounting Interred in a suitable foundation excavation
Protection rating IP67
Dimensions / weight 230 x 206 x h 88 mm / 15 kg (gearmotor with foundation case)
