Nidec Control Techniques Digitax-SF DA28C23 User Manual

47
4
Connection
Digitax SF Instruction Manual
5. Descriptions of CN1 Connector Signals
4. Connections
5. Descriptions of CN1 Connector Signals
CP
Connection to Pulse Train Command Signal
Control Mode
P S T
Use this for pulse train input in Position Control mode.
You can set the form of pulse signal input with [Pulse train command: Input mode (No.32.0)]
In case of positional disturbance due to noise, take noise countermeasures, for example,
1) Make the signal line short between the host controller and the drive.
2) Be sure to use shielded twistedpair cables for the signal lines.
3) Segregate the signal lines from the AC Supply cable and the motor power cable.
4) Adjust [Pulse train command: Input filter (No.33.0)].
dif.
24
5
Di󱐯erential
Max command pulse frequency: 4Mpps
24V open collector
Max command pulse frequency: 200kpps
Be sure to set [Pulse train command
Input lter (No.33.0)] to at least 7.
5V open collector
Max command pulse frequency: 200kpps
Be sure to set [Pulse train command
Input lter (No.33.0)] to at least 7.
FG
26
(CMDPLS）
27
(/CMDPLS）
110
Ω
330
Ω
Pulse
Direction
Shield
30
(CMDDIR）
31
(/CMDDIR）
110
Ω
330
Ω
Twisted-paircable
Drive
24V
SG
24V
28
(CC-P）
27
(/CMDPLS）
2.3k
Ω
330
Ω
29
(CC-D）
31
(/CMDDIR）
2.3k
Ω
330
Ω
FG
SG
Pulse
Direction
Shield
Twisted-paircable
Drive
5V
SG
5V
49
(CCP-5V）
27
(/CMDPLS)
390
Ω
330
Ω
50
(CCD-5V）
31
(/CMDDIR）
390
Ω
330
Ω
FG
SG
Pulse
Direction
Shield
Twisted-paircable
Drive
