Nidec Control Techniques Digitax-SF DA28C23 - Warnings and Remedies; Warning Output

5
8
Troubleshooting
8. Troubleshooting
Digitax SF Instruction Manual
2. Warnings and Remedies
2. Warnings and Remedies
Warning No. Warning Description
Encoder overheat detection
Encoder battery voltage drop error detection
Emergency stop
Encoder communication warning
Excessive position error
While a warning is being output, the user I/O WARN1 (warning) becomes closed.
4
Connections Descriptions CN1 connector signals
During warning output, the warning number will appear on the Setup Panel.
Warning status output with the RS-485 communication.
9
Appendices Status Display
There are 4 ways to output warnings.
１．I/O
2．Setup Panel Output
3．RS-485 Communication
4．Digitax SF Connect
1. Warning Output
2. Warnings and Remedies
Select the Alarm tab in Digitax SF Connect.
See [Current alarm] and [Alarm history] windows for details.
Digitax SF Connect Instruction Manual
