1. Model
3. Drive
Main Circuit Power Supply
Code Supply
Z 50 W
1 100 W
2 200 W
4 400 W
8 750 W
A 1 kW
B 1.5 kW
C 2 kW
Specications
Code Specications
22 Standard
23 Standard
Input Power Supply
Code Main Circuit Power Control Power
2 AC200 V to 240 V
(*)
DC24 V
Series
Compatible Motor
Code Model Rated Output
Y M□500□2□□＊＊ 50 W
Z M□101□2□□＊＊ 100 W
1 M□201□2□□＊＊ 200 W
2 M□401□2□□＊＊ 400 W
3 M□751□2□□＊＊ 750 W
4
M□102□2□□＊＊
1 kW
6 M□152
□2□□＊＊ 1.5 kW
8 MM202 □ 2 □ □ ＊ ＊ 2 kW
(*) Single- or Three-phase option depends on compatible motor.
50 W to 750 W
1 kW
1.5 kW, 2 kW
：Single-phase
：Single-phase / Three-phase
：Three-phase
Use a motor and the drive in a correct combination.
Drive / Motor Combinations
Drive
Motor Motor Rated Output Power
DA2YZ23 MY500 □ 2 □□
＊＊
50 W
DA2Z123 MY101 □ 2 □□
＊＊
100 W
DA21223
MX201 □ 2 □□
＊＊
, MZ201 □ 2 □□
＊＊
200 W
DA22423
MX401 □ 2 □□
＊＊
, MZ401 □ 2 □□
＊＊
400 W
DA23823
MX751 □ 2 □□
＊＊
, MZ751 □ 2 □□
＊＊
750 W
DA24A23
MM102 □ 2 □□
＊＊
1 kW
MH102 □ 2 □□
＊＊
DA26B23 MM152 □ 2 □□
＊＊
, MH152 □ 2 □□
＊＊
1.5 kW
DA28C23
MM202 □ 2 □□
＊＊
2 kW
