9
φ70
4-φ 5.5
43
□60
22.5
25
11 5
5 h9
M5
Depth10
210
30
36.5
φ14 h6
φ50 h7
LL
210
M5 (L≥12 mm)
400 W
（mm）
MX401 □ 2 □ □ ＊＊
2. Specications
1. Motor
Item Unit Specications
Rotor inertia – Low
Fitting flange size mm 60 sq.
Approximate mass
Without brake
kg
1.3
With brake 1.8
Compatible drive model – DA224 _ _
Voltage V AC200 V to 240
V
Rated output power W 400
Rated torque N･m 1.27
Instantaneous maximum torque N･m 3.82
Rated current（stall current） A 2.7
Instantaneous maximum current A 8.5
Rated revolving speed
rpm
3,000
Maximum revolving speed
rpm
6,000
Torque constant N・m / A 0.49
Induced voltage constant per phase
mV/(rpm) 17.1
Rated power rate
Without brake
kW/s
69.4
With brake 61.8
Mechanical time
constant
Without brake
ms
0.47
With brake 0.53
Electrical time constant ms 2.92
Rotor moment of
inertia
Without brake
×10
－4
k g・m
2
0.23
With brake 0.26
Item Unit Specifications
Usage – Holding
Rated voltage V DC 24 V ± 10 %
Rated current A 0.3
Static friction torque N･m
≥
1.27
Engage time ms
≤
50
Release time ms
≤
15
Release voltage V
≥
DC 1 V
Item Unit Specifications
Radial N 245
Thrust N 98
Brake Without With
Motor Model MX401N MX401A
LL 93.5 130.0
5.0
0.0
1.0
3.0
4.0
2.0
20
04
0
50
100
20
04
0
50
100
75
90
RotationalSpeedvs.Torque DeratingCurve
Withoutoilseal
Withoilseal
Torque[N･m]
Speed[rpm]
AmbientTemperature[℃]
RatedTorqueRatio[%]
AtSingle-phaseAC200V
0 600050004000300020001000 7000
Instantaneousoperationrange
Continuousoperationrange
Motor Model :
Digitax SF Instruction Manual
