108 Digistart D3: User Guide
Issue: G
11 Technical Data
Supply
Mains voltage (L1, L2, L3)
D3-14-xxxx-x ............................................................................................................. 200 Vac ~ 440 Vac (± 10%)
D3-16-xxxx-x ............................................................................................................. 380 Vac ~ 600 Vac (± 10%)
................................................................... or 380 Vac ~ 690 Vac (± 10%) for grounded star supply system only
Control voltage (CSH, CSL, CSR)
D3-xx-xxxx-x-C1 ........................................................................................... 110 ~ 210 Vac (+ 10% / -15%), 1 A
D3-xx-xxxx-x-C1 ........................................................................................... 220 ~ 440 Vac (+ 10% / -15%), 1 A
D3-xx-xxxx-x-C2 ..................................................................................................... 24 Vac/Vdc (± 20%), 100 VA
Recommended fuse
D3-xx-xxxx-x-C1 ................................................ 1 A continuous (30 A max, 10 A typical half cycle inrush)
D3-xx-xxxx-x-C2 .................................................................................................................................... 6 A
Mains frequency .................................................................................................................................... 45 Hz ~ 66 Hz
Rated insulation voltage to ground ................................................................................................................. 600 VAC
Rated impulse withstand voltage ........................................................................................................................... 4 kV
Form designation .......................................................... Bypassed or continuous, semiconductor motor starter form 1
Short circuit capability
Coordination with semiconductor fuses ............................................................................................................... Type 2
Coordination with HRC fuses .............................................................................................................................. Type 1
D3-0023-B ~ D3-0220-B ................................................................................................ prospective current 65 kA
D3-0255-B ~ D3-1000-B ................................................................................................ prospective current 85 kA
D3-0255-N ~ D3-0930-N ............................................................................................. prospective current 100 kA
D3-1200-N ~ D3-1600-N ............................................................................................... prospective current 85 kA
Electromagnetic capability (compliant with EU Directive 2014/30/EU)
EMC Immunity ....................................................................................................................................... IEC 60947-4-2
EMC Emissions
D3-0023-B to D3-1000-B (Internally bypassed models) .................................................. IEC 60947-4-2 Class B
D3-0255-N to D3-1600-N (Non-bypassed models) ......................................................... IEC 60947-4-2 Class A
1
1
This product has been designed as Class A equipment. Use of this product in domestic environments may cause
radio interference, in which case the user may be required to employ additional mitigation methods.
Inputs
Input rating ....................................................................................................................... Active 24 VDC, 8 mA approx
Start (DI1, +24V) ................................................................................................................................... Normally Open
Stop (DI2, +24V) ................................................................................................................................. Normally Closed
Reset (DI3, +24V) ............................................................................................................................... Normally Closed
Programmable inputs
Input A (DI4, +24V) ........................................................................................................................ Normally Open
Input B (DI5, +24V) ........................................................................................................................ Normally Open
Motor thermistor (TH1, TH2) .............................................................................................. Trip >3.6 k, reset <1.6 k
PT100 RTD (PT3, PT4, PT5) ..................... Accuracy 0 ~ 100 °C ± 0.5 °C, 100 °C ~ 150 °C ± 2 °C, -20 ~ 0 °C ± 2°C
Outputs
Relay outputs ......................................................................... 10 A @ 250 VAC resistive, 5A @ 250 VAC AC15 pf 0.3
Run relay (COM2, RLO2) ..................................................................................................................... Normally Open
Programmable outputs
Relay A (COM1, RLO1) ................................................................................................................. Normally Open
Relay B (COM3, RLC3, RLO3) ........................................................................................................... Changeover
Relay C (COM4, RLC4, RLO4) ............................................................................................................ Changeover
Analog output (AO1, 0V) ........................................................................................... 0-20 mA or 4-20 mA (selectable)
Maximum load .............................................................................................................. 600 (12 VDC @ 20 mA)
Accuracy ......................................................................................................................................................... ± 5%
24 VDC output (+24V, 0V)
Maximum load ............................................................................................................................................. 200 mA
Accuracy ...................................................................................................................................................... ± 10%
