60 Digistart D3: User Guide
Issue: G
Parameter Group
Parameters
Default Value
6 - Protection Delays
M
6B
Underpower Delay
00:05 (minutes:seconds)
6C
Overpower Delay
00:00 (minutes:seconds)
7 - Set Points
M
7A
Low Current Flag
50%
7B
High Current Flag
100%
7C
Motor Temperature Flag
80%
9 - Display
M
9A
Languages
9B
User Screen - Top Left
Motor Current
9C
User Screen - Top Right
Motor pf
9D
User Screen - Bottom Left
Hours Run
9E
User Screen - Bottom Right
kWh
9J
F1 Button Action
Setup Auto-Start/Stop
9K
F2 Button Action
None
9M
Display A or kW
Current
8.7 Advanced menu
The Advanced Menu gives access to all the programmable parameters in the Digistart D3. See Parameter
Descriptions on page 65.
Parameter Group
Parameters
Default Value
1 - Primary Motor Settings
M
1A
Motor Full Load Current
Model dependent
1B
Locked Rotor Current
600%
1C
Locked Rotor Time
00:10 (minutes:seconds)
1D
Motor Service Factor
105%
2 - Start/Stop Modes-1
M
2A
Start Mode
Constant Current
2B
Current Limit
350%
2C
Initial Current
350%
2D
Start Ramp Time
00:10 (minutes:seconds)
2E
Adaptive Start Profile
Constant Acceleration
2F
Kickstart Level
500%
2G
Kickstart Time
0 ms
2H
Stop Mode
Coast To Stop
2I
Stop Time
00:03 (minutes:seconds)
2J
Stop Delay
00:00 (minutes:seconds)
2K
Adaptive Stop Profile
Constant Deceleration
2L
Adaptive Control Gain
75%
2M
Brake Torque
20%
2N
Brake Time
00:01 (minutes:seconds)
2O
Auto-Start Type
Off
2P
Auto-Start Time
00:01 (hours:minutes)
2Q
Auto-Stop Type
Off
2R
Auto-Stop Time
00:01 (hours:minutes)
