Nidec Digistart D3 User Manual

Digistart D3: User Guide 61
Issue: G
Parameter Group
Parameters
Default Value
3 - Digital Inputs
M
3A
Input A Function
Starter Disable
3B
Input A Name
Starter Disable
3C
Input A Trip
Always Active
3D
Input A Initial Delay
00:00 (minutes:seconds)
3E
Input A Trip Delay
00:00 (minutes:seconds)
3F
Input B Function
Input Trip (N/O)
3G
Input B Name
Input Trip
3H
Input B Trip
Always Active
3I
Input B Initial Delay
00:00 (minutes:seconds)
3J
Input B Trip Delay
00:00 (minutes:seconds)
3K
Input C Function
Off
3L
Input D Function
Off
3M
Local/Remote
LCL/RMT Anytime
3N
Remote Reset Logic
Normally Closed
3O
Comms in Remote
Enable Control in RMT
4 - Digital Outputs
M
4A
Relay A Action
Main Contactor
4B
Relay A On Delay
00:00 (minutes:seconds)
4C
Relay A Off Delay
00:00 (minutes:seconds)
4D
Relay B Action
Run
4E
Relay B On Delay
00:00 (minutes:seconds)
4F
Relay B Off Delay
00:00 (minutes:seconds)
4G
Relay C Action
Trip
4H
Relay C On Delay
00:00 (minutes:seconds)
4I
Relay C Off Delay
00:00 (minutes:seconds)
4J
Relay D Action
Off
4K
Relay E Action
Off
4L
Relay F Action
Off
5 - Protection Settings
M
5A
Excess Start Time
00:20 (minutes:seconds)
5B
Excess Start Time-2
00:20 (minutes:seconds)
5C
Current Imbalance
30%
5D
Phase Sequence
Any Sequence
5E
Underpower
20%
5F
Overpower
400%
5G
Reserved
-
5H
Reserved
-
5I
Frequency Check
Start/Run
5J
Frequency Variation
±5 Hz
5K
Ground Fault Level
100 mA
5L
Motor Temperature Check
Do Not Check
6 - Protection Delays
M
6A
Current Imbalance Delay
00:03 (minutes:seconds)
6B
Underpower Delay
00:05 (minutes:seconds)
6C
Overpower Delay
00:00 (minutes:seconds)
6D
Reserved
-
6E
Reserved
-
6F
Frequency Delay
00:01 (minutes:seconds)
6G
Restart Delay
00:10 (minutes:seconds)
6H
Ground Fault Delay
00:03 (minutes:seconds)
