Digistart D3: User Guide 65
Issue: G
8.8 Parameter Descriptions
8.8.1 Notes on optional parameters
The following sections provide a description for all the parameters, whether available by default or optional. Optional
parameters are only available if the relevant option card is fitted to the soft starter. For a detailed list of optional
parameters, refer to the table below.
No
Function
Option card required
3K
Input C Function
NOTE
Inputs C and D are only available if the input/output
expansion card is installed.
3L
Input D Function
4J
Relay D Action
NOTE
Outputs D, E and F are only available if the input/output
expansion card is installed.
4K
Relay E Action
4L
Relay F Action
5K
Ground Fault Level
NOTE
Ground fault protection is only available if the RTD/PT100
and ground fault protection card is fitted.
6H
Ground Fault Delay
8A
Analog Input Trip
NOTE
The analog input is only available if the input/output
expansion card is installed.
8B
Analog Input Scale
8C
Analog Trip Point
8H
Analog Output B
NOTE
Analog Output B is only available if the input/output
expansion card is installed.
8I
Analog B Scale
8J
Analog B Maximum Adjustment
8K
Analog B Minimum Adjustment
14B
RTD/PT100 B °C
NOTE
PT100 inputs B ~ G are only available if the RTD/PT100
and ground fault protection card has been installed.
14C
RTD/PT100 C °C
14D
RTD/PT100 D °C
14E
RTD/PT100 E °C
14F
RTD/PT100 F °C
14G
RTD/PT100 G °C
16P
Ground Fault NOTE
Ground Fault and PT100 inputs B ~ G are only available if
the RTD/PT100 and ground fault protection card has been
installed.
16R
RTD/PT100 B
16S
RTD/PT100 C
16T
RTD/PT100 D
16U
RTD/PT100 E
16V
RTD/PT100 F
16W
RTD/PT100 G
