Nidec Digistart D3 User Manual

62 Digistart D3: User Guide
Issue: G
Parameter Group
Parameters
Default Value
7 - Set Points
M
7A
Low Current Flag
50%
7B
High Current Flag
100%
7C
Motor Temperature Flag
80%
7D
Mains Reference Voltage
400 V
8 - Analog I/O
M
8A
Analog Input Trip
Do Not Trip
8B
Analog Input Scale
2-10 V
8C
Analog Trip Point
50%
8D
Analog Output A
Current (% FLC)
8E
Analog A Scale
4-20 mA
8F
Analog A Maximum Adjustment
100%
8G
Analog A Minimum Adjustment
0%
8H
Analog Output B
Current (% FLC)
8I
Analog B Scale
4-20 mA
8J
Analog B Maximum Adjustment
100%
8K
Analog B Minimum Adjustment
0%
9 - Display
M
9A
Languages
9B
User Screen - Top Left
Motor Current
9C
User Screen - Top Right
Motor pf
9D
User Screen - Bottom Left
Hours Run
9E
User Screen - Bottom Right
kWh
9F
Graph Data
Current (% FLC)
9G
Graph Timebase
10 seconds
9H
Graph Maximum Adjustment
400%
9I
Graph Minimum Adjustment
0%
9J
F1 Button Action
Setup Auto-Start/Stop
9K
F2 Button Action
None
9L
Current Calibration
100%
9M
Display A or kW
Current
10 - Auto-Reset
M
10A
Auto-Reset Action
Do Not Auto-Reset
10B
Maximum Resets
1
10C
Reset Delay Groups A&B
00:05 (minutes:seconds)
10D
Reset Delay Group C
5 minutes
11 - Secondary Motor
Settings
M
11A
Motor FLC-2
Model dependent
11B
Dual Thermal Model
Single
11C
Locked Rotor Current-2
600%
11D
Locked Rotor Time-2
00:10 (minutes:seconds)
11E
Motor Service Factor-2
105%
