Nidec Digistart D3 User Manual

Digistart D3: User Guide 13
Issue: G
2.2.4 Minimum and Maximum Current Settings
The Digistart D3's minimum and maximum full load current settings depend on the model:
In-line connection
Inside delta connection
Model
Minimum
Maximum
Minimum
Maximum
D3-0023-B
5 A
23 A
5 A
34 A
D3-0043-B
9 A
43 A
9 A
64 A
D3-0050-B
10 A
50 A
10 A
75 A
D3-0053-B
11 A
53 A
11 A
79 A
D3-0076-B
15 A
76 A
15 A
114 A
D3-0097-B
19 A
97 A
19 A
145 A
D3-0100-B
20 A
100 A
20 A
150 A
D3-0105-B
21 A
105 A
21 A
157 A
D3-0145-B
29 A
145 A
29 A
217 A
D3-0170-B
34 A
170 A
34 A
255 A
D3-0200-B
40 A
200 A
40 A
300 A
D3-0220-B
44 A
220 A
44 A
330 A
D3-0255-B
51 A
255 A
51 A
382 A
D3-0255-N
51 A
255 A
51 A
382 A
D3-0350-B
70 A
350 A
70 A
525 A
D3-0360-N
72 A
360 A
72 A
540 A
D3-0380-N
76 A
380 A
76 A
570 A
D3-0425-B
85 A
425 A
85 A
638 A
D3-0430-N
86 A
430 A
86 A
645 A
D3-0500-B
100 A
500 A
100 A
750 A
D3-0580-B
116 A
580 A
116 A
870 A
D3-0620-N
124 A
620 A
124 A
930 A
D3-0650-N
130 A
650 A
130 A
975 A
D3-0700-B
140 A
700 A
140 A
1050 A
D3-0790-N
158 A
790 A
158 A
1185 A
D3-0820-B
164 A
820 A
164 A
1230 A
D3-0920-B
184 A
920 A
184 A
1380 A
D3-0930-N
186 A
930 A
186 A
1395 A
D3-1000-B
200 A
1000 A
200 A
1500 A
D3-1200-N
240 A
1200 A
240 A
1800 A
D3-1410-N
282 A
1410 A
282 A
2115 A
D3-1600-N
320 A
1600 A
320 A
2400 A
