22 Digistart D3: User Guide
Issue: G
Non-bypassed Models (D3-0360-N~D3-1600-N)
D3-0360-N~D3-1600-N have dedicated bypass terminals, on the input busbars. The bypass terminals are L1B, L2B,
L3B.
The busbars on non-bypassed models D3-0360-N ~ D3-1600-N can be adjusted for top or bottom input and output as
required. See Busbar Adjustment Procedure for step-by-step instructions. All units are manufactured bottom
in/bottom out.
4.1.2 Power Terminations
NOTE
For personnel safety, the power terminals on models up to D3-0105-B are protected by snap-off tabs.
When using large cables, it may be necessary to break off these tabs.
NOTE
Some units use aluminium busbars. When connecting power terminations, we recommend cleaning the
surface contact area thoroughly (using an emery or stainless steel brush) and using an appropriate jointing
compound to prevent corrosion.
Use only copper stranded or solid conductors, rated for 75 ºC or higher.
6-50 mm
2
(AWG 10-1/0)
Torque: 4 Nm (2.9 ft-lb)
14 mm (0.55 inch)
Flat 7 mm x 150
6 mm19 mm
8.5 mm
(M8)
08351.B
08352.B
6
mm
19 m
m
10
.5 m
m
(
M10
)
5 mm
28 mm
11 mm
(M10)
1
3
1
8
1
.
B
6
m
m
28 mm
11 mm
(M
10)
14543.A
1
3
mm
32 mm
11
m
m
(
M1
0
)
09866.B
6
m
m
32 mm
1
0.
5
mm
(M
1
0)
08353.B
13
mm32 mm
1
0
.5
mm
(M
10)
08
354.B
16
mm51
mm
1
2.
5
mm
(M
12)
083
55.B
