36 Digistart D3: User Guide
Issue: G
Ferraz/Mersen fuses - European style (PSC 690)
Model
SCR I
2
T (A
2
S)
Supply Voltage
(< 440 Vac)
Supply Voltage
(< 575 Vac)
Supply Voltage
(< 690 Vac)
D3-0023-B
1150
6.9URD30XXXX0050
6.9URD30XXXX0050
6.9URD30XXXX0050
D3-0043-B
8000
6.9URD30XXXX0125
6.9URD30XXXX0125
6.9URD30XXXX0125
D3-0050-B
10500
6.9URD30D11A0125
6.9URD30D11A0125
6.9URD30D11A0125
D3-0053-B
15000
6.9URD30XXXX0125
6.9URD30XXXX0125
6.9URD30XXXX0125
D3-0076-B
15000
6.9URD30XXXX0160
6.9URD30XXXX0160
6.9URD30XXXX0160
D3-0097-B
51200
6.9URD30XXXX0200
6.9URD30XXXX0200
6.9URD30XXXX0200
D3-0100-B
80000
6.9URD30D11A0200
6.9URD30D11A0200
6.9URD30D11A0200
D3-0105-B
125000
6.9URD30XXXX0315
6.9URD30XXXX0315
6.9URD30XXXX0315
D3-0145-B
125000
6.9URD30XXXX0315
6.9URD30XXXX0315
6.9URD30XXXX0315
D3-0170-B
320000
6.9URD30XXXX0315
6.9URD30XXXX0315
6.9URD30XXXX0315
D3-0200-B
320000
6.9URD31XXXX0450
6.9URD31XXXX0450
6.9URD31XXXX0450
D3-0220-B
320000
6.9URD31XXXX0450
6.9URD31XXXX0450
6.9URD31XXXX0450
D3-0255-B
320000
6.9URD31XXXX0450
6.9URD31XXXX0450
6.9URD31XXXX0450
D3-0350-B
202000
6.9URD31XXXX0550
––
––
D3-0425-B
320000
6.9URD32XXXX0630
––
––
D3-0500-B
320000
6.9URD32XXXX0700
––
––
D3-0580-B
781000
6.9URD32D11A0800
––
––
D3-0700-B
781000
6.9URD33XXXX0900
––
––
D3-0820-B
1200000
6.9URD33XXXX1100
––
––
D3-0920-B
2530000
6.9URD33XXXX1250
––
––
D3-1000-B
2530000
6.9URD33XXXX1400
––
––
D3-0255-N
320000
6.9URD31XXXX0450
6.9URD31XXXX0450
6.9URD31XXXX0450
D3-0360-N
320000
6.9URD33XXXX0630
6.9URD33XXXX0630
6.9URD33XXXX0630
D3-0380-N
320000
6.9URD33D11A0700
6.9URD33D11A0700
6.9URD33D11A0700
D3-0430-N
320000
6.9URD33XXXX0700
6.9URD33XXXX0700
6.9URD33XXXX0700
D3-0620-N
1200000
6.9URD33D11A1000
6.9URD33D11A1000
6.9URD33D11A1000
D3-0650-N
1200000
6.9URD33XXXX1000
6.9URD33XXXX1000
6.9URD33XXXX1000
D3-0790-N
2530000
6.6URD33XXXX1400
6.6URD33XXXX1400
––
D3-0930-N
4500000
6.6URD33XXXX1400
6.6URD33XXXX1400
––
D3-1200-N
4500000
6URD233PLAF2200
6URD233PLAF2200
––
D3-1410-N
6480000
6URD233PLAF2200
6URD233PLAF2200
––
D3-1600-N
12500000
6URD233PLAF2800
6URD233PLAF2800
––
XXX = blade type. See Ferraz/Mersen catalog for details.
