70 Digistart D3: User Guide
Issue: G
3E – Input A Trip Delay
Range: 0:00 - 4:00 (minutes:seconds) Default: 0 second
Description: Sets a delay between the input activating and the soft starter tripping.
3F, 3G, 3H, 3I, 3J – Input B Trip
Parameters 3F~3J configure the operation of Input B, in the same way as parameters 3A~3E configure Input A. See
Input A for details.
• 3F Input B Function (Default: Input Trip (N/O))
• 3G Input B Name (Default: Input Trip)
• 3H Input B Trip (Default: Always Active)
• 3I Input B Initial Delay (Default: 0:00)
• 3J Input B Trip Delay (Default: 0:00)
3K, 3L – Inputs C and D
Parameters 3K and 3L select the function of Inputs C and D. See parameter 3A for details.
Inputs C and D are only available if the input/output expansion card has been installed.
Options: Motor Set Select
Local/Remote Select
Emergency Run
Starter Disable (N/C)
Off (default)
3M – Local/Remote
LCL/RMT Anytime
(default)
LCL/RMT button is always enabled.
LCL/RMT button is enabled when the starter is off.
All remote inputs are disabled.
Local control buttons (START, RESET, LCL/RMT) are disabled.
Description: Selects when the LCL/RMT button can be used to switch between local and remote control, and
enables or disables the local control buttons and remote control inputs.
The STOP button on the keypad is always enabled.
WARNING
The STOP button on the keypad is always enabled. When using two-wire remote control, the soft starter
will restart if the remote start/stop and reset inputs are still active.
3N – Remote Reset Logic
Options: Normally Closed (default)
Normally Open
Description: Selects whether the Digistart D3's remote reset input (terminals DI3, +24V) is normally open or
normally closed.
3O – Comms in Remote
Options: Disable Control in RMT
Enable Control in RMT (default)
Description: Selects whether the starter will accept Start and Stop commands from the serial communication
network when in Remote mode. The Reset and Local/Remote Control commands are always
enabled.
