72 Digistart D3: User Guide
Issue: G
4E – Relay B On Delay
Range: 0:00 - 5:00 (minutes:seconds) Default: 0 second
Description: Sets the delay for changing the state of Relay B.
4F – Relay B Off Delay
Range: 0:00 - 5:00 (minutes:seconds) Default: 0 second
Description: Sets the delay for changing the state of Relay B.
4G - Relay C Action
Options:
Off
Motor overload
Main Contactor
Current imbalance
Run
Underpower
Trip (default)
Overpower
Warning
Frequency
Low Current Flag
Ground fault
High Current Flag
Heatsink overtemperature
Motor Temperature Flag
Phase Loss
Input A trip
Motor thermistor
Input B trip
Changeover Contactor
Description: Selects the function of Relay C. Relay C is a changeover relay. See Pr 4A Relay A Action for
details.
4H – Relay C On Delay
Range: 0:00 - 5:00 (minutes:seconds) Default: 0 second
Description: Sets the delay for changing the state of Relay C.
4I – Relay B Off Delay
Range: 0:00 - 5:00 (minutes:seconds) Default: 0 second
Description: Sets the delay for changing the state of Relay C.
4J – Relay D Action
Options:
Off (default)
Motor overload
Main Contactor
Current imbalance
Run
Underpower
Trip
Overpower
Warning
Frequency
Low Current Flag
Ground fault
High Current Flag
Heatsink overtemperature
Motor Temperature Flag
Phase Loss
Input A trip
Motor thermistor
Input B trip
Changeover Contactor
Description: Selects the function of Relay D (normally closed). See Pr 4A Relay A Action for details.
4K – Relay E Action
Options:
Off (default)
Motor overload
Main Contactor
Current imbalance
Run
Underpower
Trip
Overpower
Warning
Frequency
Low Current Flag
Ground fault
High Current Flag
Heatsink overtemperature
Motor Temperature Flag
Phase Loss
Input A trip
Motor thermistor
Input B trip
Changeover Contactor
Description: Selects the function of Relay E (normally open). See Pr 4A Relay A Action for details.
