Digistart D3: User Guide 83
Issue: G
8.8.15 Group 14 - RTD/PT100
The Digistart D3 has one RTD/PT100 input and can be fitted with another six PT100 inputs by using the RTD/PT100
and ground fault protection card. The inputs can trip the soft starter when the temperature exceeds a specified point,
and different trip temperatures can be set for each input.
PT100 inputs B ~ G are only available if the RTD/PT100 and ground fault protection card has been installed.
Range: 0 - 250 ° C Default: 50 ° C
Description: Sets the trip points for the RTD/PT100 inputs.
• 14A RTD A Trip Temp
• 14B RTD B Trip Temp
• 14C RTD C Trip Temp
• 14D RTD D Trip Temp
• 14E RTD E Trip Temp
• 14F RTD F Trip Temp
• 14G RTD G Trip Temp
8.8.16 Group 15 - Restricted
15A – Access Code
Range: 0000 - 9999 Default: 0000
Description: Sets the access code to control access to restricted sections of the menus.
Use the and M buttons to select which digit to alter and use the and buttons to change
the value.
NOTE
In the event of a lost access code, contact your supplier for a master access code that allows you to
re-program a new access code.
15B – Emergency Run
Options: Disable (default)
Enable
Description: Selects whether the soft starter will permit emergency run operation. In emergency run, the soft
starter will start (if not already running) and continue to operate until emergency run ends, ignoring
stop commands and trips.
Emergency run is controlled using a programmable input.
CAUTION
Continued use of Emergency Run is not recommended. Emergency Run may compromise the starter life
as all protections and trips are disabled.
Using the starter in 'Emergency Run' mode will void the product warranty.
15C – Adjustment Lock
Options:
Read & Write (default)
Allows users to alter parameter values in the Programming Menu.
Read Only
Prevents users altering parameter values in the Programming Menu.
Parameter values can still be viewed.
Description: Selects whether the keypad will allow parameters to be changed via the Programming Menu.
NOTE
Changes to the Adjustment Lock setting take effect only after the Programming Menu has been closed.
