Digistart D3: User Guide 85
Issue: G
8.8.17 Group 16 - Protection Action
These parameters define how the soft starter will respond to different protection events. The soft starter can trip,
issue a warning, or ignore different protection events as required. All protection events are written to the event log.
The default action for all protections is to trip the soft starter.
Protections 16P Ground Fault and 16R~16W RTD/PT100 are only available if the RTD/PT100 and ground fault
protection card has been fitted.
CAUTION
Defeating the protection may compromise the starter and motor, and should only be done in the case of
emergency.
16A~16X - Protection Actions
Options: Trip Starter (default)
Warn and Log
Log Only
Description: Selects the soft starter's response to each protection.
• 16A: Motor Overload
• 16B: Excess Start Time
• 16C: Current Imbalance
• 16D: Underpower
• 16E: Overpower
• 16F: Reserved
• 16G: Reserved
• 16H: Frequency
• 16I: Input A Trip
• 16J: Input B Trip
• 16K: Motor Thermistor
• 16L: Starter Communication
• 16M: Network Communication
• 16N: Heatsink Overtemperature
• 16O: Battery/Clock
• 16P: Ground Fault
• 16Q: RTD/PT100 A
• 16R: RTD/PT100 B
• 16S: RTD/PT100 C
• 16T: RTD/PT100 D
• 16U: RTD/PT100 E
• 16V: RTD/PT100 F
• 16W: RTD/PT100 G
• 16X: Low Control Volts
