Inside delta connection
AC53b 3.0-10:350
40 ºC <1000 metres
AC53b 3.5-15:345
40 ºC <1000 metres
AC53b 4.0-20:340
40 ºC <1000 metres
AC53b 4.5-30:330
40 ºC <1000 metres
D3-0023-B
34 A
30 A
26 A
22 A
D3-0043-B
64 A
59 A
51 A
44 A
D3-0050-B
75 A
66 A
55 A
45 A
D3-0053-B
80 A
80 A
69 A
55 A
AC53b 3.0-10:590
40 ºC <1000 metres
AC53b 3.5-15:585
40 ºC <1000 metres
AC53b 4.0-20:580
40 ºC <1000 metres
AC53b 4.5-30:570
40 ºC <1000 metres
D3-0076-B
114 A
96 A
83 A
70 A
D3-0097-B
145 A
123 A
104 A
87 A
D3-0100-B
150 A
132 A
112 A
92 A
D3-0105-B
157 A
158 A
143 A
117 A
D3-0145-B
218 A
184 A
159 A
136 A
D3-0170-B
255 A
217 A
181 A
146 A
D3-0200-B
300 A
283 A
241 A
213 A
D3-0220-B
330 A
315 A
268 A
238 A
D3-0255-B
382 A
346 A
302 A
264 A
D3-0255-N
382 A
346 A
302 A
264 A
D3-0350-B
525 A
494 A
427 A
366 A
D3-0360-N
540 A
540 A
465 A
395 A
D3-0380-N
570 A
570 A
539 A
449 A
D3-0425-B
638 A
617 A
533 A
458 A
D3-0430-N
645 A
645 A
552 A
464 A
D3-0500-B
750 A
668 A
575 A
490 A
D3-0580-B
870 A
738 A
637 A
546 A
D3-0620-N
930 A
930 A
810 A
651 A
D3-0650-N
975 A
975 A
842 A
683 A
D3-0700-B
1050 A
889 A
768 A
658 A
D3-0790-N
1185 A
1185 A
1075 A
868 A
D3-0820-B
1230 A
1058 A
910 A
774 A
D3-0920-B
1380 A
1206 A
1026 A
857 A
D3-0930-N
1395 A
1395 A
1244 A
992 A
D3-1000-B
1500 A
1404 A
1194 A
997 A
D3-1200-N
1800 A
1800 A
1800 A
1606 A
D3-1410-N
2115 A
2115 A
1979 A
1671 A
D3-1600-N
2400 A
2400 A
2400 A
2030 A
