Code Description Setting range Default
Mod
ify
Modbus
Addres
s
F9.19
Step T2 program
running setting
1 F/r ～ 4 F/r 1F ○ 0A13H
F9.20
Step T3 program
running setting
1 F/r ～ 4 F/r 1F ○ 0A14H
F9.21
Step T4 program
running setting
1 F/r ～ 4 F/r 1F ○ 0A15H
F9.22
Step T5 program
running setting
1 F/r ～ 4 F/r 1F ○ 0A16H
F9.23
Step T6 program
running setting
1 F/r ～ 4 F/r 1F ○ 0A17H
F9.24
Step T7 program
running setting
1 F/r ～ 4 F/r 1F ○ 0A18H
F9.25
②
Current step
running time
0.0 ～ 3600 0 * 0A19H
F9.25
③
Current
running step
1 ～ 7 0 * 0A19H
F9.26
②
Current
running step
1 ～ 7 0 * 0A1AH
F9.26
③
Current step
running time
0.0 ～ 3600 0 * 0A1AH
F9.27 Multi-step freq.8 0.00 ～ Max frequency 50.00 Hz ○ 0A1BH
F9.28 Multi-step freq.9 0.00 ～ Max frequency 50.00 Hz ○ 0A1CH
F9.29 Multi-step freq.10 0.00 ～ Max frequency 50.00 Hz ○ 0A1DH
F9.30 Multi-step freq.11 0.00 ～ Max frequency 50.00 Hz ○ 0A1EH
F9.31 Multi-step freq.12 0.00 ～ Max frequency 50.00 Hz ○ 0A1FH
F9.32 Multi-step freq.13 0.00 ～ Max frequency 50.00 Hz ○ 0A20H
F9.33 Multi-step freq.14 0.00 ～ Max frequency 50.00 Hz ○ 0A21H
F9.34 Multi-step freq.15 0.00 ～ Max frequency 50.00 Hz ○ 0A22H
F9.35
PLC Multi-step
Freq.1 selection
0:Multi-step digital
setting
0 ○ 0A23H
1: AI1 2: AI2
F9.36 PLC Multi-step 3: keypad 0 ○
0A24H
