Nidec NE200 Series User Manual

NE200&300 Quick Start Guide
31
Code Description Setting range Default Modify
Modbus
Address
F2.29
High freq.
modulation mode
0: Asynchronous
modulation
0 × 031DH
1: Synchronous
modulation
F2.31
IO output Freq.
baseline select
while vector
control
0: According to the Freq.
after ACC/DEC speed
1: According to the
current value
0 ○ 031FH
F2.32
PWM
modulation
mode
0: uplink 16Hz discrete
modulation mode
(5-stage mode),
downlink 12Hz
continuous modulation
mode (7-stage mode)
1: fixed as z continuous
modulation mode
(7-stage mode)
0 ○ 0320H
F2.33
Threshold value
of Zero Freq.
running
0.00~550.0Hz 0.00Hz ○ 0321H
F2.34
Range between
start Freq. and
threshold value
of Zero Freq.
0.00~550.0Hz 0.00Hz ○ 0322H
Group F3: Vector Control Parameters
Code Description Setting range Default Modify
M
odbus
Address
F3.00
Speed loop
proportional gain 1
1~3000 1000 ○ 0400H
F3.01
Speed loop integral
time 1
1~3000 300 ○ 0401H
F3.02
Switching
frequency 1
0.0 ～ 60.00Hz 5.00Hz ○ 0402H
F3.03 Speed loop 1~3000 800 ○ 0403H
