Code Description Setting range Default Modify
Modbus
Address
selection 1: Be saved in power
failure
2: Be cleared to 0 after
stop
F0.10
Basic
frequency
0.10 ～ 550.0Hz 50.00Hz × 010AH
F0.11
Max
frequency
MAX[50.00Hz, Freq.
upper limit, Reference
frequency]~550.0Hz
50.00Hz × 010BH
F0.12
Freq. upper
limit
Freq. lower limit ~ Max
frequency
50.00Hz × 010CH
F0.13
Freq. lower
limit
0.00~Frequency upper
limit
0.00Hz × 010DH
F0.14
Max output
voltage
110~440V
Depend
on model
× 010EH
F0.15 Carrier freq. 1.0~16.0KHz
Depend
on model
○ 010FH
F0.16
Carrier freq.
auto-adjust
0: disable
0 ○ 0110H
1: able
F0.17
Keypad
direction
0:
Forward
1: Reverse 0 ○ 0111H
F0.18
Motor wiring
direction
0: Positive sequence
0 × 0112H
1: Reversed sequence
F0.19 Acc. time1 0.1 ～ 3600s
Depend
on model
○ 0113H
F0.20 Dec. time1 0.1 ～ 3600s
Depend
on model
○ 0114H
Group F1: Start and stop control
Code Description Setting range Default Modify
Modbus
Address
F1.00 ② Start mode
0: Start directly
0 ○ 0200H
1: DC injection brake first
and then start at start freq.
