NE200&300 Quick Start Guide
39
Code Description Setting range Default Modify
Modbus
Address
③
Synchronous
motor stator
resistor Rs
1 ～ 65535mΩ(Drive rated
power≤22kW)
0.1 ～ 6553.5mΩ(Drive
rated power>22kW)
Depends
on
model
○ 060BH
F5.12
②
Synchronous
motor D-axis
inductance
Ld
0.01 ～ 655.35mH
Depends
on
model
○ 060CH
F5.12
③
Synchronous
motor D-axis
inductance
Ld
0.01 ～ 655.35mH(Drive
rated power≤22kW)
0.001 ～ 65.535mH(Drive
rated power>22kW)
Depends
on
model
○ 060CH
F5.13
②
Synchronous
motor Q-axis
inductance
Lq
0.01 ～ 655.35mH
Depends
on
model
○ 060DH
③
Synchronous
motor Q-axis
inductance
Lq
0.01 ～ 655.35mH(Drive
rated power≤22kW)
0.001 ～ 65.535mH(Drive
rated power>22kW)
Depends
on
model
○ 060DH
F5.14
Synchronous
motor
counter EMF
constant
0.0~6553.5v 300.0v ○ 060EH
Group F6: Input terminals
Code Description Setting range Default Modify
Modbus
Address
F6.00
Terminal
Command
mode
0: Two-wire mode 1
0 × 0700H 1: Two-wire mode 2
2: Three-wire mode 1
