Nidec NE200 Series User Manual

NE200&300 Quick Start Guide
40
Code Description Setting range Default Modify
Modbus
Address
3: Three-wire mode 2
F6.01
X1 terminal
Function
selection
0: NULL
1: FWD
2: REV
3: RUN
4: F/R direction
5: HLD self-hold
6: FWD jog run
(FJOG)
7: REV jog run
(RJOG)
8: RESET
9: Freq. source
switching
10: Terminal UP
11: Terminal DOWN
12: UP/DOWN setup
clear
13: Coast to stop
14: DC brake
15: Acc./Dec. prohibit
16: Drive running
prohibit
17: Multi-step terminal
1
18: Multi-step terminal
2
19: Multi-step terminal
3
20: Multi-step terminal
4
21: torque control
disable
22: Acc./Dec. time
selector 1
1 × 0701H
F6.02
X2 terminal
Function
selection
2 × 0702H
F6.03
X3 terminal
Function
selection
8 × 0703H
F6.04
X4 terminal
Function
selection
17 × 0704H
F6.05
X5 terminal
Function
selection
18 × 0705H
F6.06
③
X6
terminal
Function
selection
② AI1
terminal
function
selection
0 × 0706H
F6.07
③
X7
terminal
Function
selection
② AI2
terminal
function
selection
0 × 0707H
F6.08
②
Reserve
③
X8
Reserved × 0708H
