Nidec NE200 Series User Manual

NE200&300 Quick Start Guide
52
Code Description Setting range Default Modify
Modbus
Address
F8.16
PID output
positive limit
②
0.0~320.0Hz
③
0.0 ～ 600.0Hz
50.00Hz ○ 0910H
F8.17
PID output
negative limit
0.00 ～ 550.0Hz 0.00Hz ○ 0911H
F8.18 PID preset freq. 0.00 ～ 550.0Hz 0.00Hz × 0912H
F8.19
Hold time of PID
preset frequency
0.0 ～ 3600s 0.0s × 0913H
F8.20
Enable
dormancy
0: Disabled
1: Enabled
0 × 0914H
F8.21 Dormancy delay 0 ～ 999s 120s ○ 0915H
F8.22
Dormancy
threshold
0.0 ～ 320.0Hz 20.0Hz ○ 0916H
F8.23
Awaken
threshold
0.0~100.0%
(relative to pre-set
value)
80.00% ○ 0917H
F8.24
PID feedback
offline detection
range
0.0~100.0%
(relative to feedback
measuring range,
0.0% no detection)
0.0% ○ 0918H
F8.25
PID feedback
offline detection
time
0.0~50.0s 2.0s ○ 0919H
F8.26
PID feedback
offline detection
Min. Freq.
0.00~50.00Hz 10.00Hz ○ 091AH
Group F9: Multi-step speed and PLC
Code Description Setting range Default
Mod
ify
Modbus
Addres
s
F9.00 Multi-step freq.1 0.00 ～ Max frequency 5.00 Hz ○ 0A00H
F9.01 Multi-step freq.2 0.00 ～ Max frequency 10.00 Hz ○ 0A01H
F9.02 Multi-step freq.3 0.00 ～ Max frequency 15.00 Hz ○ 0A02H
F9.03 Multi-step freq.4 0.00 ～ Max frequency 20.00 Hz ○ 0A03H
