NE200&300 Quick Start Guide
50
Code
Description Setting range Default
Modify
Modbus
Address
datum
F7.36
Digital output
terminal
Pos./Neg. logic
Units: Logic of Y1
terminal
Tens: Reserve
Hundreds: Logic of
Relay 1
Thousands:
Reserve
0000 0824H
Digital output
terminal
Pos./Neg. logic
Units: Logic of Y1
terminal
Tens: Logic of Y2
terminal
Hundreds: Logic of
Relay 1
Thousands: Logic of
Relay 2
0000
0824H
Group F8: PID Parameters
Code
Description Setting range Default
Modify
Modbus
Address
F8.00
PID setup
channel
selection
0: PID digital setting
F8.02
0 0900H
1: AI1
2: AI2
3: Pulse input
4: serial
communication
F8.01
PID feedback
channel
selection
0: AI1
1: AI2
1 0901H
2: Pulse input
3: serial
communication
4: AI1-AI2
5: AI1+AI2
6: MAX(AI1, AI2)
7: MIN(AI1, AI2)
