NE200&300 Quick Start Guide
23
6. Run the motor
Operations Details
Before power-on Check:
No operating signal.
The motor has been connected.
1 phase 220V/ 3 phase 380V input power has been
connected correctly.
The inverter is
powered on
Confirm the inverter displays the correct operating
mode on power -up. Reset the drive if the operation
mode is incorrect. Contact your supplier if problem
still exist.
G/P model
selection
FP.05=0 Type G
FP.05=1 Type P
Set max, upper
&lower limit
frequency
F0.10 Basic frequency
F0.11 Max frequency
F0.12 Freq. upper limit
F0.13 Freq. lower limit
Set control mode F0.01=0: Sensorless vector control-1
F0.01=1: Sensorless vector control-2
F0.01=2: Vector control with encoder (NE300 only)
F0.01=3: V/F control
Set acceleration
and deceleration
time
F0.19 Acceleration time (s)
F0.20 Deceleration time (s)
Set parameters on
the motor
nameplate
F5.00 motor type
F5.01 Poles of motor
F5.02 Rated power of motor (KW)
F5.03 Rated current of motor (A)
F5.04 Rated speed of rotation of motor (RPM)
Auto-tuning of
motor
F5.10=1 (static auto-tuning) or
F5.10=2 (rotating auto-tuning, must unload) operate
the motor via keypad to perform the auto-tuning.
Run the motor Press Run button to run the motor.
Increase or decrease the speed with keypad knob.
