Code Description Setting range Default Modify
Modbus
Address
③ Stator
resistance
R1
1 ～ 65535mΩ(Drive rated
power≤22kW)
0.1 ～ 6553.5mΩ(Drive
rated power>22kW)
Depends
on
model
○
0606H
F5.07
②
Leakage
inductive
reactance X
0.01 ～ 655.35mH
Depends
on
model
○ 0607H
③ Leakage
inductive
reactance X
0.01 ～ 655.35mH(Drive
rated power≤22kW)
0.001 ～ 65.535mH(Drive
rated power>22kW)
Depends
on
model
○ 0607H
F5.08
②
Rotor
resistance
R2
1 ～ 65535mΩ
Depends
on
model
○ 0608H
③ Rotor
resistance
R2
1 ～ 65535mΩ(Drive rated
power≤22kW)
0.1 ～ 6553.5mΩ(Drive
rated power>22kW)
Depends
on
model
○ 0608H
F5.09
②
Mutual
Inductive
reactance
Xm
0.1 ～ 6553.5mH
Depends
on
model
○ 0609H
③
Mutual
Inductive
reactance
Xm
0.1 ～ 6553.5mH(Drive
rated power≤22kW)
0.01 ～ 655.35mH(Drive
rated power>22kW)
Depends
on
model
○ 0609H
F5.10 Auto tune
0: No operation
1: Static tuning
2: Rotary tuning
0 × 060AH
F5.11
②
Synchronous
motor stator
resistor Rs
1 ～ 65535mΩ
Depends
on
model
○ 060BH
