112 Chapter 6 Parameter description
F1.09 DC brake trigger frequency
at stop
Range: 0.00~max frequency
【0.00Hz】
F1.10 DC brake waiting time at
stop
Range: 0.00~10.00s【0.00s】
F1.11 DC brake current at stop Range:0.0~100.0%Drive rated
current【0.0%】
F1.11 DC brake current at stop
(Rated current)
Range: 【0.0%】
G Type: 0.0~100.0%
P Type: 0.0~80.0%
F1.12 DC brake time at stop Range: 0.0~30.0s【0.0s】
DC brake trigger frequency at stop is the frequency at which DC brake
action begins during Dec-to-stop process.
DC brake waiting time at stop: The holding time before doing the DC on
brake. During this holding time the drive stops the output. It is used to
prevent the over-current or over-voltage faults caused by DC brake when
the speed is relatively high.
DC brake current at stop: It refers to the DC braking injection amount.
The higher this value, the stronger the DC brake effect.
DC brake time at stop: It refers to the time span when DC braking is
acting.
Note:
When DC brake current or DC brake time at stop is zero, it indicates
there is no DC brake process.
F1.13 Energy consumption brake
validity
Range: 0~1【0】
0: Disabled
1: Enabled
