NE200/300 Series Drive User Manual
4 Chapter 1 Introduction to NE200/300 Series Drive
1.3.2 NE300 Product Series
 NE300−4T□□□□GB Three-phase 400V Constant torque/heavy-duty
application
Power
（
kW
）
1.5
2.2
4.0
5.5
7.5
11
15
18.5
22
30
37
45
55
75
90
110
Adapted Motor
（kW） 1.5 2.2 4.0 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110
Output
Voltage
（V） 3Phase 0~Rated input voltage
Rated
Current(A)
4 6 9 13 17 25 32 37 45 60 75 90 110 150 176 210
Overload
150%
1
min;
180%
20
sec
Input
Rated
Volt/Freq
3Phase 380V/440V; 50Hz/60Hz
Voltage
Range
304V～456V
voltage imbalance ≤3%
Allowable frequency fluctuation ±5%
Rated
Current（A）
5.4 7.0 10.7 15 20.5 27 35 38.5 46.5 62 76 92 113 157 180 214
Brake Unit
Built
-
in
Built
-
out
IP Rating
IP20
Cooling
Forced air cooling
Power（kW） 132 160 185 200 220 250 280 315 355 400 450 500 560 630 710 800
Adapted Motor
（kW）
132
160
185
200
220
250
280
315
355
400
450
500
560
630
710
800
Output
Voltage
（V） 3Phase 0~Rated input voltage
Rated
Current(A)
250 300 340 380 420 470 540 600 660 730 840 900 950 1160 1300 1460
Overload
150% 1min; 180% 20sec
Input
Rated
Volt/Freq
3Phase 380V/440V; 50Hz/60Hz
Voltage
Range
3Phase 380V/440V; 50Hz/60Hz 150% 1min;180% 20sec
Rated
Current（A）
256 307* 345 385* 430* 480* 548* 610* 670* 740* 850* 910* 960* 1170* 1310* 1470*
Brake Unit
Built
-
out
IP Rating
IP20
Cooling
Forced air
cooling
* NE300−4T1600G-F and above products are equipped with in-built DC reactor as standard.
