NE200/300 Series Drive User Manual
Chapter 6 Parameter description 125
1~5: Torque control is active
When the drive is in torque control, the drive output the torque according
to the torque command which is defined in this parameter. And the output
frequency will automatically matche to the load speed. But the output
frequency is limited F3.12.
Note:
Analog and pulse input physical quantity is corresponding to torque
setup
Torque control is valid only when the Control Mode is sensor-less
vector control-2 or vector control with encoder speed feedback.
F3.11 Torque digital setting Range: 0.0～200.0%【50.0%】
This parameter is used to define the value of torque digital setting.
F3.12 Torque control speed limit Range: 0～5【0】
This parameter is used to define the value of speed limit when the drive
is running in torque control mode.
0: digital setting (F3.13)
1: AI1
2: AI2
3: PULSE input
4: Serial communication
5: Keypad potentiometer
F3.13 Torque control speed limit
setting
Range: 0.00～550.0Hz【50.00Hz】
Setting the value of torque control upper limit digital setting (F3.12 =0).
③
F3.14 Encoder pulse number
Range: 1~9999【1000】
