NE200/300 Series Drive User Manual
Chapter 6 Parameter description 147
corresponding setup
F6.13 AI1 Max. input Range:F6.11～10.00V【10.00V】
F6.14 AI1 Max. Input
corresponding setup
Range: -200%~ 200.0%【100.0%】
F6.15 AI1 input filter time Range: 0.01～50.00s【0.05s】
F6.16 AI2 Min. input Range: 0.00～F6.18【0.00V】
F6.17 AI2 Min. Input
corresponding setup
Range: -200%~ 200.0%【0.0%】
F6.18 AI2 Max. input Range: F6.16～10.00V【10.00V】
F6.19 AI2 Max. Input
corresponding setup
Range: -200%~ 200.0%【100.0%】
F6.20 AI2 input filter time Range: 0.01～50.00s【0.05s】
F6.21 Pulse Min. input
frequency
Range: 0.00～F6.23 【0.00kHz】
F6.22 Pulse Min. input
frequency Corresponding
setup
Range: -200%~ 200.0%【0.0%】
F6.23 PULSE Max. input
frequency
Range:F6.21~50.00kHz【50.00kHz】
F6.24 PULSE input Maximum
Frequency Corresponding
setup
Range: -200%~ 200.0%【100.0%】
F6.25 Pulse filter time Range: 0.01～50.00s【0.05s】
The above function codes define the relationship between the analog
input (AI1, AI2, Pulse input) voltage and their corresponding value. When
the analog input voltage exceeds the setup maximum input or minimum
input range, the excess part will be calculated as maximum input or
minimum input, as shown in Fig.6-18.
