NE200/300 Series Drive User Manual
158 Chapter 6 Parameter description
The above parameters define output pulse frequency range.
F7.28 Auxiliary pump start lag time Range: 0～9999【0s】
F7.29 Auxiliary pump stop lag time Range: 0～9999【0s】
The above parameters define the delay time for auxiliary pump start and
stop. Refer to Fig.6-22 for details.
Fig.6-22 Constant pressure water supply auxiliary pump control signal
F7.30
Y1 Max. output Range: 0~1【0】
F7.30
DO Max. output Range: 0~1【0】
0: 50.00 kHz, Maximum output is 50kHz.
1: 500.0Hz, Maximum output is 500Hz
F7.31 FDT/RUN signal Jog
selection
Range: 0~1【0】
0: Include jog signal
1: Do not include jog signal
F7.32 Running time arrival setup Range: 0~65530 min【0】
When the drive starts running, the counting starts. Once the counting
reach to the value preset in this parameter F7.32, the drive stopping and
internal counter remains. But the run command rising edge conducts the
