NE200/300 Series Drive User Manual
Chapter 6 Parameter description 157
13 Pulse input 0.1~50.0KHz
14
Communication
setup
See Communication
appendix
15 Reserved ---
16 Output current 0~2 time rated current
F7.22
②
AO output range
selection
Range: 0~1【0】
F7.22
③
AO1 output range
selection
Range: 0~1【0】
F7.23
②
Reserved ---
F7.23
③
AO2 output range
selection
Range: 0~1【0】
0: 0~10V / 0~20mA
1: 2~10V / 4~20mA
F7.24
②
Gain of AO Range: 1~200%【100%】
F7.24
③
Gain of AO1 Range: 1~200%【100%】
F7.25
②
Reserved ---
F7.25
③
Gain of AO2 Range: 1~200%【100%】
The drive output and user’s instrument systems are likely to produce
error; you can adjust the output gain (AO1) for the meter calibration and the
change of measuring range.
F7.26
②
Y1 Maximum output
pulse freq.
Range: Y1 Minimum output pulse
freq.~50.00kHz【10.00kHz】
F7.26
③
DO Max. output pulse
freq.
Range: DO Minimum output pulse
freq.~50Hz【10.00kHz】
F7.27
②
Y1 Minimum output pulse
freq.
Range: 0.00~Y1 Maximum
output pulse frequency【0.00kH】
F7.27
③
DO Min. output pulse
freq.
Range: 0.00~DO Max. output
pulse freq.【0.00kH】
