NE200/300 Series Drive User Manual
156 Chapter 6 Parameter description
error
These parameters define the value of the analog comparison. Please
refer to table 6-6 (value 22-24) for details.
F7.19
AO function definition Range: 0～16【1】
F7.19
AO1 function definition Range: 0～16【1】
F7.20
Reserved
F7.20
AO2 output selection Range: 0～16【0】
F7.21
Y1 function definition Range: 0～16【0】
F7.21
DO output selection Range: 0～16【0】
For NE200, AO analog output is 0-10V or 0-20mA, customer can
exchange between them by switch on board. See fig. 6-8.
For NE300, AO1 can output either 0~10V or 0/4~20mA, which can be
selected by the jumper on the control board.These output selection details
are shown as table 6-8:
Table 6-8 Analog output terminals selection
Value Function Description
0 NULL NULL
1 Running frequency 0~maximun frequency
2 setting frequency 0~maximun frequency
3 output current 0～2* drive rated current
4 Output voltage 0～Maximum Voltage
5 PID setup 0～10V
6 PID feedback 0～10V
7 Calibration signals 5V
8 Output torque 0～2*motor rated torque
9 Output power 0～2*Drive rated power
10 DC Bus voltage 0～1000V
11 AI1 0～10V
12 AI2 0～10V
