NE200/300 Series Drive User Manual
202 Appendix A Modbus Communication Protocol
Fb.07 Gain of location loop 0.001~10.00 1.000 o 0C07H
FC Protection and Fault
FC.20
Reminding or not while
undervoltage
0 ： Yes
1 ： No
Note
：
Include digital output,
reading the communication
fault code. 0 means that it is
same with before.
o 0D14H
Fd Communication
Fd.10 CAN communication
0 ： Disable
1 ： Enable
0 o 0E0AH
Fd.11
CAN communication
baud rate
0 ： 20KBPS
1 ： 50KBPS
2 ： 125KBPS
3 ： 250KBPS
4 ： 500KBPS
5 ： 1MBPS
3 o 0E0BH
Fd.12
Receiving ID of CAN
(High byte)
18F8H 0~1FFFH o 0E0CH
Fd.13
Receiving ID of CAN
(Low byte)
2238H 0~FFFFH o 0E0DH
Fd.14 Receiving interval time
0.0~100.0s
Note ：
0.0s means there is no
‘receiving interval time’.
The drive will give
the communication fault
feedback if the interval
time is over the set value
after communication is
connected.
0.0s o 0E0EH
Fd.15
Transmitting ID of CAN
（ High byte ） 1
18F8H 0~1FFFH o 0E0FH
Fd.16
Transmitting ID of CAN
（ Low byte ） 1
2247H 0~FFFFH o 0E10H
Fd.17
ID1 data transmitting
time interval
0.1~500.0ms 100.0ms o 0E11H
Fd.18
Transmitting ID of CAN
（ High byte ） 2
18F8H 0~1FFFH o 0E12H
Fd.19
Transmitting ID of CAN
（ Low byte ） 2
2248H 0~FFFFH o 0E13H
Fd.20
ID2 data transmitting
time interval
0~5000ms
Don’t transmit data while
Value is 0.
500ms o 0E14H
Fd.21
ID2 data transmitting
1
0 ： Output Freq.
1 ： Given Freq.
0 o 0E15H
