NE200/300 Series Drive User Manual
Appendix A Modbus Communication Protocol 201
F6.31
Delay duration of X2
terminal open
0.0~100.0s 0.0s o 071FH
F6.32
Pos. and Neg. logic
terminal X 1
Pos. and Neg. logic of Xi
terminal: Pos. logic
：
Be
valid while connecting Xi and
COM. Neg. logic
：
Be valid
while disconnecting Xi and
COM.
Units
：
Logic of X1
Tens
：
Logic of X2
Hundreds
：
Logic of X3
Thousands
：
Logic of X4
0000 x 0720H
F6.33
Pos. and Neg. logic
terminal X 2
Units: Logic of X5 terminal
Tens: Logic of X6 terminal
Hundreds: Logic of X7
terminal
Thousands: Logic of X8
terminal
Note:
Terminal 24
、
25
、
26
、
27
、
42
、
43
、
44 and 49 are not
impacted by this parameter.
0000 x 0721H
F7 Output terminal
F7.00~F7.04
DO~ Relay digital
output
29
：
Running in FWD
30
：
Running in REV
31
：
Instantaneous power
loss processing
o
F7.19~F7.21
Ao1/Ao2/Pulse output
15
：
Output signal of speed
loop given by Iq
Range: -150.0~150.0%
0
F7.34
Ao1 4mA/2.00v
adjustable datum
0.0~100.0% 20.0% o 0822H
F7.35
Ao2 4mA/2.00v
adjustable datum
0.0~100.0% 20.0% o 0823H
F7.36
Digital output terminal
Pos./Neg. logic
Units: Logic of Y1 terminal
Tens: Logic of Y2 terminal
Hundreds: Logic of Relay 1
Thousands: Logic of Relay 2
0000 o 0824H
Fb Fixed Length
Fb.05
Motor return initial
location automatically
0
：
Valid
1
：
Valid this function while
the set Freq. is lower
than the Freq. of motor
return the initial location
2
：
Valid this function by
terminal
x 0C05H
Fb.06
Initial Freq. of ‘Motor
return initial location
automatically’
0.00~10.00Hz 1.00Hz o 0C06H
