76 Chapter 5 List of Parameters
Code Description Setting range Default Modify
Modbus
Address
F6.28
Delay
duration of X1
terminal close
0.0~100.0s 0.0s ○ 071CH
F6.29
Delay
duration of X1
terminal open
0.0~100.0s 0.0s ○ 071DH
F6.30
Delay
duration of X2
terminal close
0.0~100.0s 0.0s ○ 071EH
F6.31
Delay
duration of X2
terminal open
0.0~100.0s 0.0s ○ 071FH
F6.32
Pos. and Neg.
logic terminal
X 1
Pos. logic of Xi
terminal:
Be valid while
connecting between Xi
and COM.
Neg. logic of Xi
terminal:
Be valid while
disconnecting
between Xi and COM.
Units: Logic of X1
terminal
Tens: Logic of X2
terminal
Hundreds: Logic of X3
terminal
Thousands: Logic of
X4 terminal
0000 × 0720H
F6.33
② Pos. and
Neg. logic
terminal X 2
Units: Logic of X5
terminal
Tens: Logic of AI1
terminal
Hundreds: Logic of
AI2 terminal
0000 × 0721H
