NE200/300 Series Drive User Manual
Chapter 5 List of Parameters 77
Code Description Setting range Default Modify
Modbus
Address
Note:
Terminal 24、25、26、27、
42、43、44 and 49 are not
impacted by this
parameter.
F6.33
③ Pos. and
Neg. logic
terminal X 2
Units: Logic of X5
terminal
Tens: Logic of X6
terminal
Hundreds: Logic of X7
terminal
Thousands: Logic of
X8 terminal
Note:
Terminal 24、25、26、27、
42、43、44 and 49 are not
impacted by this
parameter.
0721H
Group F7: Output terminal
Code Description Setting range Default Modify
Modbus
Address
F7.00
② Reserve
0: NULL
1: RUN
2: Freq. arrival(FAR)
3: Freq. level
detection 1 (FDT1)
4: Freq. level
detection 2 (FDT2)
5: Freq. detection
when speed-up
6: Freq. detection
when speed-down
7: Zero-speed
running
Reserve Reserve 0800H
③
DO terminal
output definition
0 ○ 0800H
F7.01
Y1 terminal
output selection
1 ○ 0801H
F7.02
② Reserve Reserve Reserve 0802H
③
Y2 terminal
output
selection
0 ○ 0802H
