Nikon D850 - Flash Info for Shoe-Mounted Units

198
The camera can display flash info for flash units that support
unified flash control (the SB-5000, SB-500, SB-400, and SB-300)
mounted on the camera accessory shoe. To view flash info, press
the R button in the information display (0 203). The
information displayed varies with the flash control mode.
❚❚ TTL
❚❚ Auto External Flash
Flash Info for Shoe-Mounted Units
5
7
8
9
6
4
213
1 Flash-ready indicator................. 187
2 Bounce icon (displayed if flash
head is tilted upwards)
3 Zoom head position warning
(displayed if zoom head position
is not correct)
4 Flash control mode.................... 190
FP indicator.................................. 266
5 Flash compensation (TTL)
.............................................. 190, 194
6 Flash mode .................................. 192
7 Flash control mode.................... 201
8 FV lock indicator......................... 196
9 Flash compensation .................. 194
1
2
1 Flash control mode.................... 190
FP indicator.................................. 266
2 Flash compensation (auto
aperture) ............................ 190, 194
