Chapter 3 Individual Operations
154
Individual
Operations
Units Supported for Buttons
Operation Button Target Unit
[INTSL]
Shutter built in the HG precentered fiber illuminator
[FL TURRET]
Shutter built in the epi-fluorescence cube turret on the 1st layer (default setting)
[FL 2nd]
Shutter built in the epi-fluorescence cube turret on the 2nd layer
[EPI/DIA/AUX]
Motorized shutter connected to the EPI SHUTTER connector at the position set in “(2)
Configuring the Device Connection Information”
FL SHUTTER Button
[EPI/DIA/AUX]
Motorized shutter connected to the DIA SHUTTER connector at the position set in “(2)
Configuring the Device Connection Information”
[OFF]
Inactive
[USB]
Camera directly controlled by DS-L3 connected to the USB connector (default setting)
[NOT-CONNECTED/FRONT/LEFT/AUX]
Camera connected to DSC1 at the position set in “(2) Configuring the Device
Connection Information”
CAPTURE Button
[NOT-CONNECTED/FRONT/LEFT/AUX]
Camera connected to DSC2 at the position set in “(2) Configuring the Device
Connection Information”
[L: FL / R: OBJ.]
OBJ CW/CCW button (on the lateral left) for the epi-fluorescence cube turret on the
1st layer, FL CUBE CW/CCW button (on the lateral right) for the motorized nosepiece
[L: OBJ. / R: FL]
OBJ CW/CCW button (on the lateral left) for the motorized nosepiece, FL CUBE
CW/CCW button (on the lateral right) for the epi-fluorescence cube turret on the 1st
layer (default setting)
CW/CCW Button
[L: OBJ. / R: OBJ.]
OBJ CW/CCW button (on the lateral left) and FL CUBE CW/CCW button (on the
lateral right) for the motorized nosepiece
To Next Page
