Nikon ECLIPSE Ni-E User Manual

Chapter 3 Individual Operations
85
Individual
Operations
Microscope State Display
Pattern 1 Top
Bottom
Objective, Z-axis position (unit: um)
Dia-illumination status, field diaphragm status (unit:
mm)
PA__2x____Z:_____0.000um
DIA:ON__________FS30.6mm
Pattern 2 Top
Bottom
Objective, Z-axis position (unit: um)
Optical path selection, zoom magnification, field
diaphragm status (unit: mm)
PA__2x____Z:_____0.000um
BINO____ZM:1.0x_ FS30.6mm
Pattern 3 Top
Bottom
Objective, Z-axis position (unit: um)
Status of the epi-fluorescence cube turret (1st
layer)/status of epi-fluorescence cube turret's
built-in shutter (1st layer), HG precentered fiber
illuminator ND status/HG precentered fiber
illuminator shutter status, EPI motorized shutter
status
PA__2x____Z:_____0.000um
UV-2B
'
C __=_ND_ 1
'
C __EPI:C
Pattern 4 Top
Bottom
Objective, Z-axis position (unit: um)
Status of the epi-fluorescence cube turret (1st
layer)/status of epi-fluorescence cube turret's
built-in shutter (1st layer), zoom magnification
status, motorized ND filter wheel status (unit: %)
PA__2x____Z:_____0.000um
UV-2B
'
C _ ZM:1.0x_ ND:_ 0.0%
Pattern 5 Top
Bottom
Objective, Z-axis position (unit: um)
Condenser status, aperture diaphragm status (unit:
mm), field diaphragm status (unit: mm)
PA__2x____Z:_____0.000um
BF____AS30.6mm__FS30.6mm
Pattern 6 Top
Bottom
Status of the epi-fluorescence cube turret (1st
layer)/epi-fluorescence cube turret's built-in shutter
(1st layer), X-axis position (unit: um)
Zoom magnification, Y-axis position (unit: um)
UV-2B
'
C __=X:___==0.000um
ZM:1.0x___Y:_____0.000um
Pattern 7 Top
Bottom
Objective, X-axis position (unit: um)
Zoom magnification, Y-axis position (unit: um)
PA__2x___=X:___==0.000um
ZM:1.0x___Y:_____0.000um
Pattern 8 Top
Bottom
BA (barrier) filter status, status of the
epi-fluorescence cube turret (2nd layer)/status of
epi-fluorescence cube turret's built-in shutter (2nd
layer)
EX (excitation) filter status, status of the
epi-fluorescence cube turret (1st layer)/status of
epi-fluorescence cube turret's built-in shutter (1st
layer), EPI motorized shutter status
BA400_____DAPI_ -2
'
C
EX330-380_ UV-2B
'
C __EPI:C
Pattern 9 Top
Bottom
Objective status, status of epi-fluorescence cube
turret (1st layer)/status of epi-fluorescence cube
turret's built-in shutter (1st layer), EPI motorized
shutter status
Condenser status, zoom magnification, field
diaphragm status (unit: mm)
PA__2x____UV-2B
'
C __EPI:C
BF______ZM:1.0x_ FS30.6mm
When a motorized device is not connected
The corresponding field will be displayed as blank. If the information for the device (i.e. objective) is not set, it will be
displayed as “-----”.
DS-L3 MICROSCOPE INFORMATION Screen
When DS-L3 is connected to the microscope, you can check the status of the microscope on the DS-L3
[MICROSCOPE INFORMATION] screen. See Chapter 2 “3.3 MICROSCOPE INFORMATION Screen (Ni-E)” in the
“Microscope Operation” Instruction Manual provided with DS-L3.
