111Service Manual – SC5000 24 - Electrical System
8-E003 Charge timed out
Description
Setting
Conditions
When Monitored
Charging
Possible Causes
Initial Action
Troubleshooting Steps
• Charger output reduced due to high temperatures. Operate at lower ambient temperature.
• Charger output reduced due to low AC voltages. Check AC voltage.
• Check for shorted or damaged cells.
• Poor battery health. Replace battery.
• Very deeply discharged battery. Retry charge.
• Poorly connected battery. Check connections.
• This error will automatically clear once the charger is reset by cycling DC or by loss of AC for over 10
minutes.
8-E004 Battery below min volt
Description
Battery could not be trickle charged up to the minimum voltage. May also be used for
other battery-related errors depending on the algorithm.
Setting
Conditions
When Monitored
Charging
Possible Causes
Initial Action
Troubleshooting Steps
• Check for shorted or damaged cells.
• Poor battery health. Replace battery.
• Check DC connections.
• This error will automatically clear once the charger is reset by cycling DC or by loss of AC for over 10
minutes.
