187Service Manual – SC5000 34 - Scrub System, Disc
Specications
Parameter Range
Brush Motor Amperage 31 amps max.
Lift Actuator Amperage
Special Tools
Actuator Test Kit
The actuator test kit (Pn 56407502) is used to
manually control an actuator removed from the
machine, but powered from a 36-volt battery. It
contains alligator clips to connect to the battery,
a reversing power switch, and a cable connector.
If your test kit is prior to Rev I, you will also need
a second adapter cable (Pn 56123352) to connect
between the tester and the actuator. These adaptors,
1-male and 1-female, are included in kits Rev I and
above.
