118Service Manual – SC5000 24 - Electrical System
8-E029 CAN bus error
Description Cannot transmit on CAN bus
Setting
Conditions
When Monitored
Charging
Possible Causes
The CANBus has to be functional for this error to be reported to the Main Machine
Controller.
Initial Action
Troubleshooting Steps
1. Disconnect AC input and battery for 30 seconds.
2. Reconnect the battery rst, and then plug the charger into facility power for 30 seconds.
3. If error persists, replace the charger
8-E030 CAN HeartBeat-1 timeout
Description CAN heartbeat timeout from Main Machine Controller
Setting
Conditions
When Monitored
Charging
Possible Causes
The CANBus has to be functional for this error to be reported to the Main Machine
Controller.
Initial Action
Troubleshooting Steps
1. Disconnect AC input and battery for 30 seconds.
2. Reconnect the battery rst, and then plug the charger into facility power for 30 seconds.
3. If error persists, replace the charger
8-E031 ADC Vref out of range
Description The Vref for the ADC measurements has triggered an alarm
Setting
Conditions
When Monitored
Charging
Possible Causes
Initial Action
Troubleshooting Steps
1. Disconnect AC input and battery for 30 seconds.
2. Reconnect the battery rst, and then plug the charger into facility power for 30 seconds.
3. If error persists, replace the charger
