Nilfisk-Advance Advance SC5000

72Service Manual – SC5000 04 - Control System
J5 Drive Controller
Pin# Wire Color Function Observations
1 W165 GRY Potentiometer Gnd 0V
2 W195 YEL CAN-1 H 2.6V
3 W196 GRN CAN-1 L 2.5V
4 W163 BLU-GRY Seat Switch In Open = 0.02V, Seated = B+
6 W164 BLU-YEL E-Stop In Closed = B+, Open/Active = 0.02V
7
8 W193 PNK-YEL Programmer Data N/A
9 W194 PNK-BLU Programmer Clock N/A
10 W166 RED Potentiometer +5V N/A
11
12 W198 RED-ORG +15V Out 13.3V
13 W168 VIO Throttle In (Pot Wiper) 1.0 to 4.0V through full range movement
14
15 W173 VIO Motor Temperature In 1.18V = -114°C (faulty thermocouple)
16
17
18 W189 GRY I/O Ground 0V
19 W188 VIO-GRN Encoder A
AC V = 2.78 at full speed
0 V at park
20 W187 VIO-ORN Encoder B
21 W186 VIO-YEL Encoder C
22 W162 YEL KSI In B+
23
24
Motor Lugs
U
0 to 12.7 V AC, from parked to full speed
Machine raised off the ground
V
W
