73Service Manual – SC5000 04 - Control System
J6 Power Module
Pin# Wire Color Function Observations
1 W232 BRN-GRY Deck Actuator - Down = 3.8 V, Up = 34.2 V, Stationary = 3.8 V
2 W019 BRN K2 Coil Out
3 W245 GRN CAN-1 L
4 W244 YRL CAN-1 H
5 W240 RED Curtis Prog +15V
6 W231F BRN-RED Deck Actuator + Down = 37 V, Up = 0.1 V, Stationary = 0 V
7 W242 PNK-YEL Curtis Prog RX
8 W243 PNK-BRN Curtis Prog TX
9 W202 YEL KSI In B+
10 W233F BLU-RED Opt. Pump +
11 W234 BLU-GRY Opt. Pump -
12 W241 BLK Curtis Prog Gnd
13 W230 BRN-WHT Squeegee Act. + Down = 3.7 V, Up = 37 V, Stationary = 3.7 V
14 W229F GRN-RED Squeegee Act. - Down = 37 V, Up = 0 V, Stationary = 0 V
To Next Page
