Scrub System, Cylindrical 75Service Manual – SC3000
Check/replacement/adjustment of driving belts between motors and cylindrical brushes
Check
1. Drive the machine on a level oor.
2. Lower the brush deck by pressing the scrub On/Off push button .
3. Turn the ignition key to “0” and disconnect the batteries.
4. On both sides of the machine, unscrew the knobs and remove the side skirt assemblies.
5. Remove the screws (A) and remove the covers (B).
6. Visually inspect the driving belt (C) for integrity, cuts, tears or cracks and, if necessary, replace it
according to the following procedure.
7. Check the driving belt tension (C) according to the following procedure.
A
B
C
P100380
