Control System - Battery Version 23Service Manual – SC450
Component Location
Brush switch (SW1)
Vacuum system switch (SW2)
Brush activation push-button (SW3)
Battery voltage LEDs
Function electronic board (EB1)
LED electronic board (EB2)
Wiring harness
Brush switch (SW1)
Vacuum system switch (SW2)
Battery voltage LEDs
Function
electronic
board (EB1)
Wiring harness
LED
electronic
board (EB2)
Brush activation
push-buttons (SW3) *SW4(
Brush activation
push-buttons (SW3) (SW4)
P200007
